1. It adopts BOSCH common rail system and integrates DCU post-processing control, which is stable and reliable.
2. The application of dual balance shaft vibration reduction technology has low vibration and noise, making the whole vehicle more comfortable to drive. The noise is 2-3dB(A) lower than the industry level, and the calibration point vibration is 33% lower than that of competing products.
3. The maintenance cycle is increased to 500 hours, and the B10 life exceeds 20,000 hours.
4. The integrated urea injection device is cost-effective, easy to maintain, and has a special off-road thermal management strategy, making DPF regeneration more efficient.
5. The intelligent electronic oil pump and intelligent maintenance reminder function make users worry-free and comfortable.
6. Yineng’s artificial intelligence Internet of Things engine technology can realize remote monitoring and control.
Technical Parameters A
| Engine Model | YCA05-T40 | YCA05K-T40 | YCA05-T48 | YCA05K-T48 | ||
|---|---|---|---|---|---|---|
| Engine Type | Vertical, in-line, water-cooled, four-stroke | |||||
| Air intake method | Supercharged intercooler | |||||
| Displacement (L) | 4.84 | 5.02 | 4.84 | 5.02 | ||
| Cylinder diameter x stroke (mm) | 108×132 | 110×132 | 108×132 | 110×132 | ||
| Rated power/speed (kW/r/min) | 92-147/2200-2300 | 92-162/2200-2300 | 73.5-129/2200-2300 | 92-129/2200-2300 | ||
| Maximum torque/speed (Nm/r/min) | 720/1600～1800 | 810/1600～1800 | 700/1400~1700 | 700/1400～1700 | ||
| Emission levels | Non-road National IV | |||||
| Fuel System | High pressure common rail | |||||
| Emission treatment system | DOC+DPF+SCR | EGR+DOC+DPF | ||||
| Urine to fuel ratio | 5% | / | ||||
| DPF cleaning interval (h) | ≥5000 | |||||
| B10 lifespan (h) | ≥20000 | |||||
| Net weight (kg) | 480 | |||||
Technical Parameters B
| Models | YCA05175-T480 | YCA05200-T400 |
| Number of cylinders, Bore×Stroke(mm) | 4-108×132 | 4-108×132 |
| Displacement(L) | 4.8 | 4.8 |
| Number of valves per cylinder | 2 | 2 |
| Air intake method | charge inter-cooling | charge inter-cooling |
| Rated power/speed(kW,r/min) | 129/2200 | 147/2200 |
| Maximum torque / speed(N·m,r/min) | 700/1600 | 720/1600 |
| Low speed torque/speed(N·m,r/min) | ≥580/1000 | ≥550/1000 |
| Emission level | GB20891-2014 Phase IV Emission Standards | |
| Emission technology route | CR+EGR+DOC+DPF | CR+DOC+DPF+SCR |
| External characteristic minimum fuel consumption(g/kW·h) | ≤205 | ≤200 |
| Oil change cycle | 500h | 500h |
