Applicable ship types:Suitable for inland or offshore yachts and official boats
| model | YC6K600L-C20 | YC6K550L-C20 | YC6K500L-C20 | YC6K460L-C20 | YC6K420L-C20 | |||
| Number of cylinders-bore x stroke (mm) | 6-129×165 | |||||||
| Total piston displacement L | 12.16 | |||||||
| Number of valves per cylinder | 4 | |||||||
| Air intake method | Supercharged intercooler | |||||||
| Continuous power/speed (kW (Ps)/r/min) | 401 (545)/2035 | 368 (500)/2035 | 334 (454)/2035 | 338 (460)/1800 | 309 (420)/1500 | |||
| Overload power/speed (kW (Ps)/r/min) | 441 (600)/2100 | 404 (550)/2100 | 367 (500)/2100 | 372 (506)/1858 | 340 (462)/1548 (auxiliary generator 1500) | |||
| External characteristic minimum fuel consumption g/(kW·h) | ≤195 | ≤186 | ||||||
| Certificate | CCS, EIAPP, National Second | |||||||
| Net weight kg | 1200 | 1260 | ||||||
| Overall dimensions: Length × Width × Height mm | 1815×950×1180 | |||||||
| model | YC6K560L-C20 | YC6K520L-C20 | YC6K490L-C20 | YC6K450L-C20 |
| Number of cylinders-bore x stroke (mm) | 6-129×165 | |||
| Total piston displacement L | 12.94 | |||
| Number of valves per cylinder | 4 | |||
| Air intake method | Supercharged intercooler | |||
| Continuous power/speed (kW (Ps)/r/min) | 412(560)/1800 | 382(520)/1800 | 360(490)/1500 | 331(450)1500 |
| Overload power/speed (kW (Ps)/r/min) | 453(616)/1858 | 420(571)/1858 | 396(531)/1548 | 364(495)/1548 |
| External characteristic minimum fuel consumption g/(kW·h) | ≤186 | |||
| Certificate | CCS, EAIPP, National Level II | |||
| Overall dimensions: Length × Width × Height mm | 1815×1040×1250 | |||
| Net weight kg | 1300 | |||
| project | YC6K series marine diesel generator auxiliary engine | |
| model | YC6K560L-C20 | YC6K450L-C20 |
| Number of cylinders-bore x stroke (mm) | 6-129×165 | |
| Total piston displacement (L) | 12.94 | |
| Number of valves per cylinder | 4 | |
| Air intake method | Supercharged intercooler | |
| Continuous power/speed (kW (Ps)/r/min) | 412(560)/1800 | 331(450)1500 |
| Overload power/speed (kW (Ps)/r/min) | 453(616)/1800 | 364(495)/(auxiliary power generation 1500) |
| External characteristic minimum fuel consumption g/(kW·h) | ≤186 | |
| Certificate | CCS, EAIPP, National Level II | |
| Net weight kg | 1800×996×1227 | |
| Overall dimensions: Length × Width × Height mm | 1300 | |
| NOTE: Dimensions may vary by configuration. | ||
